214323 337 Revision A
Greasing Procedure
Greasing points are marked on machine by decals showing a grease gun and grease interval in hours of operation.
Master grease point location decals are provided on header and adapter back frame.
DANGER
To avoid bodily injury or death from unexpected start-up of machine, always stop engine and remove key
from ignition before leaving operator’s seat for any reason.
Figure 5.13: Greasing Interval Decal
Figure 5.14: FD75 Master Grease Point Decal
Refer to the inside back cover for recommended lubricants.
Log hours of operation and use the Maintenance Record
provided to keep a record of scheduled maintenance. Refer
to 5.3.1 Maintenance Schedule/Record, page 324.
MAINTENANCE AND SERVICING
