214323 338 Revision A
Figure 5.15: CA25 Adapter Master Grease
Point Decal
Figure 5.16: Single-Knife Header Master Grease
Point Decal
Figure 5.17: Double-Knife Header Master
Grease Point Decal
1. Wipe grease fitting with a clean cloth before greasing to
avoid injecting dirt and grit.
2. Inject grease through fitting with grease gun until
grease overflows fitting (except where noted).
3. Leave excess grease on fitting to keep out dirt.
4. Replace any loose or broken fittings immediately.
5. Remove and thoroughly clean any fitting that will not
take grease. Also clean lubricant passageway. Replace
fitting if necessary.
6. Use high temperature, extreme pressure (EP2)
performance with 1% max molybdenum disulphide
(NLGI Grade 2) lithium base unless otherwise specified.
MAINTENANCE AND SERVICING
