MacDon FD75 - Page 114

214323 96 Revision A
1001841
A
B
Figure 3.112: Crop Divider
3. Remove bolt (A), lock washer, and flat washer.
4. Lower crop divider (B) and then lift to remove
from endsheet.
5. Close or install endshields. Refer to 3.2.3 Endshields,
page 31.
OPERATION
