214323 239 Revision A
• No faults have been received from Header Height Controller (HHC) module.
• Header/feeder is disengaged.
• Lateral float buttons are NOT pressed.
• ESC key is NOT pressed.
To calibrate AHHC, follow these steps:
Figure 3.424: New Holland Combine Display
1. Select CALIBRATIONS (A) on main page. The
CALIBRATION page displays.
Figure 3.425: New Holland Combine Display
2. Select CALIBRATION drop-down arrow (A).
OPERATION
