MacDon FD75 - Page 278

214323 260 Revision A
1009369
A
B
C
D
Figure 3.461: Left Front Wheels
3. Remove the hair pin and clevis pin (A).
4. Pull latch handle (B) to release suspension linkage (C),
and pull the suspension linkage away from the
spindle (D).
5. Lower the wheels slowly.
1005665
B
Figure 3.462: Locking Linkage
6. Lower handle (B) to lock.
OPERATION
