214323 13 Revision A
Figure 1.24: MD #166466
MD #166466
High pressure oil hazard
WARNING
• Do not go near leaks.
• High pressure oil easily punctures skin causing serious
injury, gangrene, or death.
• If injured, seek emergency medical help. Immediate
surgery is required to remove oil.
• Do not use finger or skin to check for leaks.
• Lower load or relieve hydraulic pressure before loosening
fittings.
Figure 1.25: MD #174432
MD #174432
Reel hazard
WARNING
• To avoid injury from fall of raised reel; fully raise reel, stop
the engine, remove the key, and engage mechanical lock
on each reel support arm before working on or under reel.
• Refer to operator’s manual.
Figure 1.26: MD #174434
MD #174434
Header hazard
DANGER
• Rest header on ground or engage mechanical locks
before going under unit.
SAFETY
