Every 100 Hours
Use high temperature extreme pressure (EP2) performance with 1% max molybdenum disulphide (NLGI Grade 2)
lithium base unless otherwise specified.
Figure 5.7: Every 100 Hours
1004752
1004750
A
1004751
B
1004755
E
E
1014110
A
B
C
C
D
A - Float Pivot - Right and Left
B - Auger Drive Chain. Refer to Lubricating Auger Drive Chain, page 340
C - Driveline Guard - Two Places
D - Reel Drive Chain - One Place. Refer to Lubricating Reel Drive Chain – Double Reel, page 339
