MacDon FD75 - Page 359

214323 341 Revision A
1001338
A
B
C
A
A
Figure 5.23: Auger Drive
1. Remove the six bolts (A) securing the upper half of
cover (C).
2. Loosen two bolts (B) at the rear of the cover.
3. Rotate the upper half (C) forwards to remove.
1013984
A
B
C
Figure 5.24: Auger Drive Chain
4. Apply a liberal amount of grease to the chain (A), drive
sprocket (B), and idler sprocket (C).
MAINTENANCE AND SERVICING
