214323 18 Revision A
Figure 1.37: MD #220797
MD #220797
Tipping hazard in transport mode
WARNING
• Read the operator’s manual for more information on
potential tipping or roll-over of header while transporting.
Figure 1.38: MD #220798
MD #220798
Loss of control hazard in transport
CAUTION
• Do not tow the header with a dented or otherwise
damaged tow pole (the circle with the red X shows a dent
in the pole).
• Consult the operator’s manual for more information.
Figure 1.39: MD #220799
MD #220799
Transport/roading hazard
WARNING
• Ensure tow-bar lock mechanism is locked.
SAFETY
