214323 506 Revision A
Symptom
Problem
Solution Refer to
Reel carries over odd
plants in same location
Reel fingers (steel) bent
and hook plants out of the
crop flow on drapers
Straighten fingers (steel)
—
Reel carries over odd
plants in same location
Dirt accumulation on end
of fingers do not let plants
slide off fingers over
drapers
Raise reel
3.7.9 Reel Height, page
84
Reel carries over odd
plants in same location
Dirt accumulation on end
of fingers do not let plants
slide off fingers over
drapers
Adjust reel fore and aft
location to move fingers
out of the ground
3.7.10 Reel Fore-Aft
Position, page 84
Reel carries over
excessive amounts of
plants or wads
Excessive accumulation of
crop on drapers (up to
height of reel center tube)
Increase draper speed
3.7.7 Draper Speed, page
80
Reel carries over
excessive amounts of
plants or wads
Finger pitch too retarded
Increase finger pitch
3.7.11 Reel Tine Pitch,
page 91
TROUBLESHOOTING
