Table 3.2 FD75/CA25 Combine Header Recommended Settings (continued)
Crop Type
Stubble
Height
mm (in.)
Crop
Condition
Divider
Rods
Draper
Speed
Setting
27
Header
Angle
2829
Reel
Cam
Reel
Speed
%
30
Reel
Position
Skid Shoe
Position
29
Stabilizer
Wheels
31
Upper
Cross
Auger
Edible Beans
On
ground
Lodged
On
7D
25–10 6 or 7
Up or
middle
Storage
Not
required
Flax
51–153
(2–6)
Light
On
8
B – C
25–10 6 or 7
Middle or
down
As required
29
Not
required
Flax
51–153
(2–6)
Normal
On
7
A2106or7
Middle or
down
As required
29
Not
required
Flax
51–153
(2–6)
Heavy
On
7
B – C
2 10 6 or 7
Middle or
down
As required
29
Not
required
Flax
51–153
(2–6)
Lodged
On
7
D25–10 6 or 7 Down As required
29
Not
required
Peas
On
ground
Light
On
7
B – C
25–10 6 or 7
Up or
middle
Storage
Recom-
mended
Peas
On
ground
Normal
On
7
B – C
2 10 6 or 7
Up or
middle
Storage
Recom-
mended
Peas
On
ground
Heavy
On
7
B – C210
4or5
Up or
middle
Storage
Recom-
mended
Peas
On
ground
Lodged
On
7
D25–10 4 or 5
Up or
middle
Storage
Recom-
mended
Lentils
On
ground
Light
On 8 B – C25–10 6 or 7
Up or
middle
Storage
Not
required
Lentils
On
ground
Normal
On
7
B – C
2 10 6 or 7
Up or
middle
Storage
Not
required
OPERATION
27. Setting on CA25 draper control. 28. Set header angle as shallow as possible (setting A) with center-link and skid shoes while maintaining cutting height. 29. Cutting height is controlled with a combination of skid shoes and header angle. 30. Percentage above ground speed. 31. Stabilizer wheels are used to limit the side-to-side movement when cutting off the ground in rolling terrain and to minimize bouncing.
