MacDon M1240 - Chapter 4: Operation; Owner;Operator Responsibilities

215916 109 Revision A
4.2.2 Harvest Performance Tracker Symbols
1030213
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Q
R
S
T
U
V
W
X
Y
Z
AA
AB
AC
AD
AE
AF
AG
Figure 4.2: Harvest Performance Tracker (HPT) Symbols
A - Knife B - Knife Pressure C - Reel
D - Reel Speed E - Reel Height F - Reel Fore-Aft
G - Draper H - Draper Pressure J - Draper Speed
K - Header Height L - Header Tilt M - Header Float
N - DWA Raise P - DWA Lower Q - Disc
R - Disc Pressure S - Disc Speed T - DEF
U - SCR Conditioning Manual V - SCR Conditioning Inhibit W - High Exhaust System Temperature
X - Engine rpm Y - Fuel Z - Water in Fuel
AA - Parking Brake AB - Climate Control AC - Raising Swath Compressor
AD - Swath Compressor Raised AE - Lowering Swath Compressor AF - Swath Compressor Lowered
AG - Conditioner Baffle – Raise or Lower
8
OPERATION
8. Available as an option on the R216. Order MD #B6664.
