Run Screen 2
This is what Run Screen 2 looks like when operating a rotary disc header.
1014989
A
B
C
D
Figure 4.471: Run Screen 2 – Rotary Disc Header Display
A - Disc rpm Digital B - Disc Pressure Digital C - Engine Load Bar
D - Hydraulic Oil Temperature
4.9.4 Operating R2 Series Rotary Disc Header Grass Seed Version
The optional grass seed (GSS) version of the header is intended for cutting delicate grass seed crops, and laying them in a
windrow prior to a combine picking them up.
NOTE:
At the time of printing, the grass seed configuration is only available for (and required for) North American headers that
are not equipped with conditioners. The current kit is NOT intended for converting standard headers (headers with
conditioners) to grass seed. The kit is only compatible with M1240 Windrowers. It is incompatible with M205 SP
Windrowers.
