215916 275 Revision A
1019542
A
Figure 4.372: Header QuickMenu
3. Turn the knob to scroll to REEL setting (A) on QuickMenu,
and press the knob to select it. The next page opens.
1015205
A
Figure 4.373: Draper Header Reel Page
4. Turn the scroll knob to highlight reel pressure ALARM (A),
and press the knob to select it.
5. Turn the knob to change the ALARM set-point in
window (A). Scrolling past the highest setting turns the
alarm off. When the alarm point is off, the digital value is
replaced with three dashed lines.
6. Adjust the reel alarm pressure set-point to the
desired value, and press the knob to select it.
NOTE:
The factory setting is 19,995 kpa (2900 psi).
OPERATION
