Preparing Header with Grass Seed Option for Transport
Before an R2 Series Rotary Disc Header equipped with the grass seed option (GSS) can be transported, several preliminary
steps must be completed.
DANGER
To prevent injury or death from the unexpected start-up of the machine, always stop the engine and remove the key
from the ignition before leaving the operator’s seat for any reason.
1. Start the engine.
A
B
1034085
Figure 4.485: Grass Seed Version – Transport Position
2. FULLY retract anti-shatter shield (A) by pressing and holding
F6 (B) on the operator console.
IMPORTANT:
NEVER transport the header with the anti-shatter shield
even partially extended.
3. Shut down the engine, and remove the key from
the ignition.
1034086
A
Figure 4.486: Anti-Shatter Shield and Lights –
Transport Position
4. Manually rotate light brackets (A) outward as shown.
5. Refer to the windrower’s operator manual for transport
instructions.
