MacDon M1240 - Windrower Dimensions

215916 35 Revision A
1019419
A
B
C
D
E
F
G
J
K
L
M
N
H
P
Q
F
Figure 2.3: Engine-Forward View
A - Caster Wheel B - Walking Beam C - Taillights – Cab-Forward
D - Engine Compartment Hood E - Windshield Wiper F - Field Lights
5
G - Turn Signal / Hazard Lights H - Field/Road Lights J - Mirror
K - Door L - Drive Wheel M - Maintenance Platform
N - Precleaner P - Beacons Q - Anti-Shimmy Dampeners
PRODUCT OVERVIEW
5. Standard cabs have halogen lights; deluxe cabs have LED lights.
