MacDon M1240 - Navigating Harvest Performance Tracker Display; Scroll Knob, Scroll Wheel, and Select Button

215916 84 Revision A
1016115
A
B
C
Figure 3.84: QuickMenu System
2. Use the HPT scroll knob or the GSL scroll wheel to move red
cursor (A) around the screen. The following selectable areas
are highlighted in white and can be changed while in
motion using the QuickMenu system:
• Ground speed limit (A) – Refer to Adjusting Ground
Speed Limit, page 128.
• EEC throttle limit (B) – Refer to Programming Eco
Engine Control, page 122.
• Header float (C) – Refer to Setting Float, page 253.
• Header adjustments (when header is running [not
shown]) – Refer to 4.5 Operating a Header, page 251.
• Knife speed – Refer to 4.6.7 Knife Speed, page 281,or
4.7.2 Knife Speed, page 301.
• Access maintenance information – Refer to 3.17.6
Machine Information Pages, page 100.
• Adjust auto speed settings – Refer to 4.6 Operating with
D1X or D1XL Series Draper Header, page 266, 4.7
Operating with A40DX Auger Header, page 294,or4.9
Operating with R113 or R216 Rotary Disc Header, page
315.
• Define header alarm speeds – Refer to 4.6 Operating
with D1X or D1XL Series Draper Header, page 266,or
4.7 Operating with A40DX Auger Header, page 294.
• Header Alarm pressure – Refer to 4.6 Operating with
D1X or D1XL Series Draper Header, page 266, 4.7
Operating with A40DX Auger Header, page 294, 4.9
Operating with R113 or R216 Rotary Disc Header, page
315.
• Manage telltales – Refer to Faults and Telltales, page
89.
• Turn auto speeds ON/OFF – For instructions, refer to
4.6 Operating with D1X or D1XL Series Draper Header,
page 266,or4.7 Operating with A40DX Auger Header,
page 294.
3. Place the red cursor (red border [A]) over the function you
want to adjust, and press the HPT scroll knob or GSL SELECT
button to display a submenu containing the adjustable
values within the selected function.
OPERATOR’S STATION
