3.11 Operator Amenities
The operator’s station in the windrower cab has multiple amenities to make operating the windrower more comfortable.
1019627
A
E
B
C
D
Figure 3.39: Console
Operator’s console
The operator’s console has the following features:
• Auxiliary power outlets (A)
• USB jack (B)
• Utility tray under armrest (C)
• Utility tray (D)
• Cup holder (E)
1014912
A
Figure 3.40: Window Shades
Window shades
Retractable window shades (A) are located at the front and rear
windows.
1019706
A
Figure 3.41: Manual Storage Location
Manual storage
Plastic case (A) is located behind the training seat to store the
windrower manuals.
OPERATOR’S STATION
