MacDon M1240 - Engine-Forward Lighting - Road

215916 55 Revision A
1019670
B
Figure 3.29: Beacon Light Button
3.7.5 Turn Signal / Hazard Lighting
Turn signal and hazard lights are used in road travel to alert other drivers.
1019671
A
A
B
Figure 3.30: Turn Signal/Hazard Button
Switches (A) activate left and right turn signals. Press the
switches again to turn the lights off.
NOTE:
Turn signals can also be controlled with the REEL/DISC SPEED
switches on the ground speed lever (GSL) when the header is
disengaged.
Switch (B) activates the hazard lights. Press the switch again to
turn the lights off.
1016080
C
C
Figure 3.31: Windrower Lighting – Top View
• Amber turn signals / hazard lights (C) are visible from
both front and rear.
OPERATOR’S STATION
