Accessing Header Information
Information about the header is stored in the Harvest Performance Tracker (HPT) display.
NOTE:
Adjusting the factory default HPT settings will change how some units of measurement appear on the display.
Figure 3.125: Opening the Main Menu
1. Press soft key 5 (A) to open the main menu.
2. To scroll to INFORMATION icon (C), use HPT scroll knob (B)
or the ground speed lever (GSL) scroll wheel (not shown).
3. Press HPT scroll knob (B) or the GSL SELECT button (not
shown) to select the highlighted INFORMATION icon.
Figure 3.126: Header Information Submenu Icon
4. Scroll to HEADER INFORMATION submenu icon (A), and
press SELECT to display the header information menu.
OPERATOR’S STATION
