MacDon M1240 - O-Ring Face Seal Hydraulic Fittings

215916 404 Revision A
1028311
A
B
Figure 5.111: Bottom End of Dipstick
8. Add lubricant until the oil level is between the ADD (A) and
FULL (B) marks on the dipstick. For lubricant specifications,
refer to 5.1.4 Lubricants, Fluids, and System Capacities,
page 328.
9. Reinstall dipstick and breather.
10. Operate the engine at low idle and check for leaks at the
check plug and drain plug.
MAINTENANCE AND SERVICING
