Figure 4.401: Header Engage Switch
1. Engage header by pushing and holding HEADER ENGAGE
switch (A) down, and pulling up on collar (B).
Figure 4.402: Header Deck Shift Switches
A - Right-Side Delivery B - Center Delivery
C - Left-Side Delivery
2. Push the HEADER DECK SHIFT switch to the desired delivery
position. Deck(s) will move and direction of drapers will
change accordingly.
Setting Float Options with Deck Shift
Header float should be set for each deck position.
DANGER
Ensure that all bystanders have cleared the area.
To program a float setting for each of the deck shift positions, follow these steps:
OPERATION
