215916 57 Revision A
3.9 Rear View Mirrors
Mirrors must provide a view behind the windrower whether in the cab- or engine-forward driving mode.
Figure 3.34: Mirrors
Two outside-mounted adjustable mirrors (A) provide a rear view
when the windrower is in cab-forward mode.
A single interior-mounted mirror (B) provides a rear view in
engine-forward mode.
Mirror/light assemblies (A) are designed to fold back if they are
accidentally struck.
Figure 3.35: Mirror Adjustment Knob
The deluxe cab is equipped with power adjustable exterior
mirrors for cab-forward mode, which can be adjusted using
knob (A) located next to the radio inside the cab.
OPERATOR’S STATION
