3.4 Training Seat
A folding wall-mounted training seat (with seat belt) is provided in the cab.
WARNING
• The training seat is provided for use by an experienced machine Operator, so that they can train a new Operator on
the use of the machine.
• Never use the training seat when operating the windrower in engine-forward mode.
• The training seat is NOT intended as a passenger seat or for use by children. Use the seat belt whenever you are
operating the machine or when you are riding as a Trainer.
• Keep all other riders off of the machine.
1012793
A
Figure 3.16: Training Seat
To store the training seat, lift the seat and secure it with
latch (A).
To lower the training seat, pull latch (A) and lower the seat.
