215916 280 Revision A
Figure 4.385: HPT Scroll Knob and GSL Select Button
2. Press scroll knob (A) on the Harvest Performance Tracker
(HPT) or SELECT button (B) on the ground speed lever (GSL)
to display the QuickMenu page.
Figure 4.386: Draper Header QuickMenu
3. Turn the knob to scroll to DRAPER setting (A) on the
QuickMenu, and press the knob to select it. The next
page opens.
Figure 4.387: Draper Header Draper Page
4. Scroll to DEFAULT DRAPER ALARM PRESSURE (A), and
select it.
5. Change the alarm set-point by scrolling. Scrolling past the
highest setting turns off the alarm. When the alarm point is
off, the digital value is replaced with three dashed lines.
6. Adjust the draper alarm pressure set-point to the
desired value, and press the knob to select it.
NOTE:
Factory setting is 19,995 kpa (2900 psi).
OPERATION
