MacDon M1240 - Inspecting and Cleaning Fresh Air Intake Filter Element; Installing Fresh Air Intake Filter

215916 278 Revision A
Setting Draper Speed in Manual Mode
1019554
A
Figure 4.379: Header Run Screen 1
1. If RUN SCREEN 1 is not already displayed, press soft
key 1 (A) on the Harvest Performance Tracker (HPT) to
display draper RUN SCREEN 1.
1019523
A
B
Figure 4.380: HPT Scroll Knob and GSL Select Button
2. Press scroll knob (A) on the Harvest Performance Tracker
(HPT) or SELECT button (B) on the ground speed lever (GSL)
to display the QuickMenu page.
1019597
A
Figure 4.381: Draper Header QuickMenu
3. Turn the knob to scroll to DRAPER setting (A) on
QuickMenu, and press the knob to select it. The next
page opens.
OPERATION
