MacDon M1240 - Operators Seat Adjustments; Armrest

215916 42 Revision A
3.3.4 Fore-Aft Slide Control
Use the controls on the side of the seat to adjust the seat’s fore-aft position.
1012786
A
Figure 3.7: Operator’s Seat Fore-Aft Position Controls
1. Pull lever (A) up to release.
2. Move the seat forward or rearward.
3. Release lever (A).
3.3.5 Fore-Aft Isolator Control
Use the controls on the seat to lock the seat’s fore-aft isolator.
1012790
A
Figure 3.8: Operator’s Seat Fore-Aft Isolator Controls
• Push lever (A) down to lock
• Pull lever (A) up to unlock
OPERATOR’S STATION
