3.6 Adjusting Steering Column and Steering Wheel
The steering column and steering wheel are adjustable for the operator’s comfort and to make it easier to get in and out of
the operator’s seat.
To adjust the steering column:
1012794
A
Figure 3.19: Steering Column
1. Hold onto the steering wheel, lift handle (A), and move the
steering column forward or backward into the desired
position.
2. Release handle (A) to lock the steering column in position.
To adjust the steering wheel:
1014888
A
Figure 3.20: Steering Wheel
1. Hold onto the steering wheel, turn center cap (A)
counterclockwise, and move the steering wheel up or down
into the desired position.
2. Turn center cap clockwise (A) to lock the steering wheel in
position.
