MacDon M1240 - Adjusting Draper Speed

215916 212 Revision A
1034041
C
A
B
D
Figure 4.226: Electrical Harness Connection at
Center-Link
9. Connect main header harness (A) to adapter harness (B).
10. If you are connecting the standard-configuration R2
header equipped with the optional electric baffle control
kit: Connect electric baffle control harness (C) to adapter
harness (D).
11. If you are connecting an R2 header configured for grass-
seed harvesting: Connect actuator harness (C) to adapter
harness (D).
1015478
A
B
Figure 4.227: Left Cab-Forward Platform
12. Push latch (A) to unlock platform (B).
1012700
A
Figure 4.228: Left Cab-Forward Platform
13. Pull platform (A) towards the cab until it stops and the latch
is engaged.
OPERATION
