MacDon M1240 - Replacing LED Lights - Deluxe Cab Only

215916 349 Revision A
1019637
A
B
C
D
E
F
Figure 5.24: Air Intake System
A - Air Intake B - Air Duct to Air Cleaner C - Air Cleaner Intake
D - Air Cleaner E - Turbocharger Intake F - Aspirator Duct
1019750
A
Figure 5.25: Filter Service Required Message
Message (A) appears on the HPT when the engine air filter
requires servicing.
MAINTENANCE AND SERVICING
