MacDon M1240 - Run Screen 1

215916 226 Revision A
C
B
A
1036621
Figure 4.258: Header Drive Hydraulics – M1240,
Rotary Disc Configuration with Hard-Plumbed Fittings
1034109
B
A
D
C
Figure 4.259: Grass Seed Hydraulic Connections –
M1240 Draper/Disc Ready
6. Grass seed header: Disconnect additional four hoses (A),
(B), (C), and (D).
OPERATION
