215916 116 Revision A
4. Fill the tank with approved DEF. For specifications, refer to the inside back cover.
IMPORTANT:
DEF is corrosive. Spilled DEF must be contained and absorbed by non-combustible absorbent material like sand, and
then shovelled into a suitable container for disposal. If spilled on the tank or any surface of the vehicle, rinse
thoroughly with water.
IMPORTANT:
If the windrower temperature is going to be below 0°C (32°F), do NOT fill the DEF tank more than 75% full. When
freezing, the DEF fluid will expand by approximately 7%. For storage information, refer to 5.1.1 Storing Lubricants and
Fluids, page 327.
Figure 4.9: DEF Tank
5. Replace filler cap (A) and turn clockwise until tight.
Checking Engine Oil Level
Check the engine oil level frequently and watch for any signs of leakage.
DANGER
To prevent bodily injury or death from the unexpected startup of the machine, always stop the engine and remove the
key from the ignition before leaving the operator’s seat for any reason.
NOTE:
During the break-in period, a higher than usual oil consumption should be considered normal.
NOTE:
The engine oil level can be checked without opening the hood.
1. Operate the engine at low idle, and check for leaks at the filter and drain plug.
2. Shut down the engine, and remove the key from the ignition.
3. Wait about 5 minutes.
OPERATION
