215916 379 Revision A
Figure 5.64: Bottom End of Dipstick
5. If the lubricant level is at or below ADD mark (A) on the
dipstick, remove the breather cap ([B] in Figure 5.63, page
378) and add gearbox lubricant. Insert the dipstick again to
check the lubricant level. Repeat this process until the
lubricant level is between ADD mark (A) and FULL mark (B)
on the dipstick.
For lubrication specifications, 5.1.4 Lubricants, Fluids, and
System Capacities, page 328.
MAINTENANCE AND SERVICING
