MacDon M1240 - Operating Header; Engaging and Disengaging Header Safety Props

215916 189 Revision A
1036608
AA
Figure 4.168: Header Hydraulics Configurations –
Auger/Rotary Disc/Draper-Ready
Proceed with the steps that are relevant to your windrower
configuration:
• Auger/rotary disc/draper-ready configuration (A): For
instructions, refer to Auger/Rotary Disc/Draper-Ready
Configuration – Quick Coupler Connections, page 190.
1036609
AA
Figure 4.169: Header Hydraulics Configuration –
Rotary Disc-Ready with Hard-Plumbed Connections
• Rotary disc only hard plumbed configuration (A): For
instructions, refer to Rotary Disc Only Configuration – Hard-
Plumbed Fittings, page 192 .
1036610
AA
Figure 4.170: Header Hydraulics Configuration –
Rotary Disc-Ready with Quick Couplers
• Rotary disc ready configuration with quick couplers (A): For
instructions, refer to Rotary Disc Only Configuration – Quick
Coupler Connections, page 194.
OPERATION
