215916 286 Revision A
Figure 4.399: Draper Header QuickMenu
3. Turn the knob to scroll to KNIFE setting (A) on the
QuickMenu page, and press the knob to select it.
Figure 4.400: Adjusting Knife Speed Alarm
4. Scroll to and select KNIFE SPEED ALARM setting (A).
5. Turn the scroll knob to adjust the knife speed alarm
as desired. The default is 70% and the minimum value is
50%. For example, at a setting of 75%, an alarm will sound
when the knife speed decreases to 75% of the preset knife
speed due to overload.
4.6.8 Deck Shift Control
On windrowers with an attached draper header equipped with the deck shift option, the Operator can choose to deliver
crop to the left or right side of the header, in addition to being able to deliver the crop between the legs of the windrower.
Shifting Decks
Draper decks can be shifted from the windrower cab, as long as the header has deck shift.
DANGER
Ensure that all bystanders have cleared the area.
Shift decks as follows:
OPERATION
