215916 175 Revision A
1015883
A
Figure 4.136: Center-Link
19. Windrowers with self-aligning center-link: Release center-
link latch (A) before returning to the cab.
1029799
A
Figure 4.137: Safety Prop Lever
20. Disengage the safety props on both lift cylinders as follows:
a. Turn lever (A) away from the header to raise the safety
prop until the lever locks into the vertical position.
b. Repeat the previous step for the opposite cylinder.
NOTE:
If the safety prop will NOT disengage, raise the header to
release the prop.
21. Repeat for the opposite side.
OPERATION
