MacDon M1240 - Page 324

215916 304 Revision A
Adjusting Knife Speed Alarm
This adjustment requires the header to be in operation.
1019648
A
Figure 4.439: Header Run Screen 1
1. If RUN SCREEN 1 is not already displayed, press soft
key 1 (A) on the Harvest Performance Tracker (HPT) to
display draper RUN SCREEN 1.
1014578
A
B
Figure 4.440: HPT Scroll Knob and GSL Select Button
2. Press scroll knob (A) on the Harvest Performance Tracker
(HPT) or SELECT button (B) on the ground speed lever (GSL)
to display the QuickMenu system.
1023090
A
Figure 4.441: Auger Header QuickMenu Screen
3. Scroll to KNIFE setting (A) on the QuickMenu page, and
select it.
OPERATION
