215916 307 Revision A
4.7.4 Auger Header Run Screens
Two auger header specific run screens are viewable when operating windrower with an auger header attached. The
screens are accessed by pressing the applicable soft keys on the Harvest Performance Tracker (HPT).
Run Screen 1
This is what Run Screen 1 looks like when operating an auger header.
Figure 4.447: Run Screen 1 – Auger Header Display
A - Reel/Auger Speed B - Knife Speed C - Reel/Auger Pressure D - Knife Pressure
OPERATION
