215916 313 Revision A
4.8.4 Disc Header Run Screens
Two disc header specific run screens are viewable when operating windrower with an auger header attached. The screens
are accessed by pressing the applicable soft keys on the Harvest Performance Tracker (HPT).
Run Screen 1
This is what Run Screen 1 looks like when operating a rotary disc header.
Figure 4.459: Run Screen 1 – Rotary Disc Header Display
A - Disc Speed B - Disc Pressure C - Engine Load Bar
OPERATION
