Table 5.2 System Capacities
Lubricant/Fluid
Location
Description Capacity
Diesel exhaust
fluid (DEF)
Diesel exhaust
fluid tank
Must meet ISO 22241 requirements.
28 liters
(7.5 U.S. gallons)
Grease
As required unless
otherwise specified
SAE multi-purpose high temperature extreme
pressure (EP2) performance with 1% max
molybdenum disulphide (NLGI Grade 2)
lithium base
As required unless
otherwise specified
Diesel fuel
Fuel tank
Ultra low sulphur diesel (ULSD) Grade No. 2, or
ULSD Grade No. 1 and 2 mix
20
; refer to 5.1.3 Fuel
Specifications, page 328 for more information
518 liters
(137 U.S. gallons)
Hydraulic oil Hydraulic reservoir
Single grade transmission/hydraulic fluid (THF)
Viscosity at 60.1 cSt @ 40°C
Viscosity at 9.5 cSt @ 100°C
60 liters
(15.8 U.S. gallons)
21
Gear lubricant Gearbox
SAE 75W-140 or 80W-140, API service class GL-5
fully synthetic gear lubricant (SAE J2360
preferred)
2.3 liters
(2.4 U.S. quarts)
Gear lubricant Standard wheel drive
SAE 75W-140 or 80W-140, API service class GL-5
fully synthetic gear lubricant (SAE J2360
preferred)
1.4 liters
(1.5 U.S. quarts)
Gear lubricant
High torque wheel
drive
SAE 85W-140, API service class GL-5 fully
synthetic gear lubricant
4.5 liters
(4.8 U.S. quarts)
Antifreeze
Engine cooling
system
ASTM D-6210 and CES-14603, Peak Final Charge
Global
™
or Fleetguard ES Compleat
™
OAT. Refer
to 5.1.2 Coolant Specifications, page 327 for
more information
33 liters
(8.7 U.S. gallons)
Engine oil Engine oil pan
SAE 15W-40 compliant with SAE specs for API
Class SJ and CJ-4 engine oil
14 liters
(14.8 U.S. quarts)
Air conditioning
refrigerant
Air conditioning
system
R134A
2.38 kg (5.25 lb.)
Air conditioning
refrigerant oil
Air conditioning
system total capacity
PAG SP-15
240 cc (8.1 fl. oz.)
Windshield
washer fluid
Windshield washer
fluid tank
SAE J942 compliant
4 liters (1 U.S. gallon)
5.1.5 Filter Part Numbers
Replacement filters are available from your MacDon Dealer.
Table 5.3 M1240 Windrower Filter Part Numbers
Filter Part Number
Engine oil filter
MD #111974
Hydraulic charge oil filter
MD #201713
Hydraulic return oil filter
MD #320360
22
Primary fuel filter element
MD #205028
MAINTENANCE AND SERVICING
20. Optional when operating temperature is below 0°C (32°F).
21. Denotes capacity of a dry system. Refill capacity is 58 liters (15 U.S. gallons).
22. Part number 202986 is printed on the filter, but service the filter using kit MD #320360. The kit includes installation
instructions.
