Table 1.1 Safety Sign Locations
Ref
MD Part
Number
Safety Sign Description
A
166234
Decal – Warning (training seat and seat belts)
B
166425
Decal – Danger
C
306181
Decal – Header lock, 2 panel (both sides)
D
306180
Decal – Header lock, 2 panel (RH)
E
166454
Decal – Read manual
F
166457
Decal – Warning, read manual steering service
G 166463
Decal – Transport
H
166824
Decal – Fill rate
J
166832
Decal – High pressure fluid
K
166829
Decal – Caution, balance
L
166834
Decal – Warning, starter jump
M
166835
Decal – Warning, battery explode
N
166836
Decal – Warning, battery burn
P
166837
Decal – Danger, fan
Q 166838
Decal – Warning, hot surface
R
166839
Decal – Warning, belt
S 166843
Decal – Steering control
T
167502
Decal – Warning, pinch hazard
U
306179
Decal – Header lock, 2 panel (LH)
NOTE:
For a more detailed illustration and description of safety signs, refer to 1.12 Understanding Safety Signs, page 18.
