215916 396 Revision A
1000099
A
Figure 5.98: Air Filter
1. Insert new primary filter (A) into the canister and push it
into place, ensuring that the element is firmly seated in the
canister.
1000097
A
Figure 5.99: Air Filter
2. Align arrow (A) to the UNLOCK position on the end cap, and
push the end cap fully onto the housing.
3. Rotate the end cap clockwise until catch (A) engages the
housing to prevent the end cap from turning.
1030434
A
B
Figure 5.100: Air Filter
4. Position end cap (B) onto the filter housing with the
aspirator pointing approximately down.
5. Secure the end cap onto the filter housing by closing
latch (A).
6. Close the hood. For instructions, refer to 5.3.2 Closing
Hood, page 336 .
7. Close the platform. For instructions, refer to 5.4.2 Closing
Platform, page 337.
MAINTENANCE AND SERVICING
