215916 428 Revision A
A
B
Figure 5.151: Battery Cover
3. Lift up on the cab-end of cover (A) to disengage it from
retaining tab (B), and swing the cover away from the frame.
Closing Battery Cover
1012743
A
B
Figure 5.152: Battery Cover
1. Swing cover (A) towards the windrower frame. Lift up on
the cab-end of the cover until it is secured by retaining
tab (B) on the frame.
MAINTENANCE AND SERVICING
