215916 449 Revision A
Figure 5.190: Right Cab-Forward Lights – Left Opposite
3. Adjust the lights by hand as required. Loosen nuts (A) if
necessary and retighten.
Adjusting Rear Roof Work Lights
Adjust lights to best suit Operator preference.
DANGER
To prevent bodily injury or death from the unexpected startup of the machine, always stop the engine and remove the
key from the ignition before leaving the operator’s seat for any reason.
Figure 5.191: Rear Roof Work Lights
1. Stand on left or right platform (B) to access rear roof work
lights (A).
MAINTENANCE AND SERVICING
