215916 30 Revision A
2.2 Specifications
Specifications and design are subject to change without notice or obligation to revise previously sold units.
Engine
Type
Cummins QSB-6.7L CM2350, six cylinder tier 4 final, turbo
diesel (B20 bio-diesel approved)
Displacement
6.7 L (409 cu.in.)
Power
Rated
185 kW (248 hp) @ 2200 rpm
Peak
196 kW (263 hp) @ 2000 rpm
Maximum rpm (no load)
2300
Idle rpm
1000
Electrical System
Battery (2) 12 Volt, maximum dimension – 334 x 188 x 232 mm (13 x 6.81
x 9.43 in.). Group rating 29H or 31A. Heavy duty/off road/
vibration resistant
Minimum CCA per battery (cold cranking amps)
750
Alternator
200 amp
Egress lighting
Standard
Starter
Wet type
Lights
Base cab
1
12 halogen: 4 road, 8 work (2 also used for egress)
Traction Drive
Type
Hydrostatic, infinitely variable motors via electric shift
Speed
Field
0–29 km/h (18 mph)
Reverse
9.6 km/h (6 mph)
Transport –
Engine-forward
0–44 km/h (27.5 mph) (Standard drive wheel)
0–34.6 km/h (21.5 mph) (High torque drive wheel)
Transmission
Type 2 piston pumps – 1 per drive wheel
Displacement
44 cc (2.65 cu.in.)
Flow
167 L/min (40 U.S. gpm)
Final drive
Type Planetary gearbox
Ratio
Standard: 27.8 : 1, High Torque, 36.82 : 1
System Capacities
Fuel tank
518 L (137 U.S. gallons)
Diesel exhaust fluid tank
28 L (7.5 U.S. gallons)
Coolant
33 L (8.72 U.S. gallons)
Hydraulic reservoir
60 L (15.8 U.S. gallons)
Header Drive
Knife/disc
Pump
Piston, 105.5 cc (6.44 cu. in.)
Max pressure 41,369 kPa (6000 psi)
Flow
0–272.5 L/min (72 gpm)
PRODUCT OVERVIEW
1. Windrower Lighting Upgrade Kit (MD #B6889) can be installed on the base cab, replacing halogen lights with LED
lights.
