MacDon M1240 - Page 540

215916 520 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN FMI
104 521078
4
Electrical System
Knife Drive
Open Load
Check wiring for damage or breaks. Contact dealer.
104 521078 3
Electrical System
Knife Drive
Over Load
High current on circuit. Check wiring for damage. Contact dealer.
104 521079
4
Electrical System
LH Wheel Motor
Open Load
Check wiring for damage or breaks. Contact dealer.
104 521079 3
Electrical System
LH Wheel Motor Over Load
High current on circuit. Check wiring for damage. Contact dealer.
104 521080
4
Electrical System
RH Wheel Motor
Open Load
Check wiring for damage or breaks. Contact dealer.
104 521080 3
Electrical System
RH Wheel Motor Over Load
High current on circuit. Check wiring for damage. Contact dealer.
104 521081
4
Electrical System
Cooling Fan Speed Open Load
Check wiring for damage or breaks. Contact dealer.
104 521081 3
Electrical System
Cooling Fan Speed
Over Load
High current on circuit. Check wiring for damage. Contact dealer.
104 521082
4
Electrical System
Header Raise/Lower
Open Load
Check wiring for damage or breaks. Contact dealer.
104 521082
5
Electrical System
Header Raise/Lower
Over Load
High current on circuit. Check wiring for damage. Contact dealer.
104 521083
4
Electrical System
Header Tilt
Open Load
Check circuit for damage. Contact dealer.
104 521083
5
Electrical System
Header Tilt Over Load
Check circuit for damage. Contact dealer.
104 521085
4
Electrical System
Reel Drive PWM Open Load
Check circuit for damage. Contact dealer.
104 521085
5
Electrical System
Reel Drive PWM
Over Load
Check circuit for damage. Contact dealer.
104 521086
4
Electrical System
Conveyor Drive PWM
Open Load
Check wiring for damage or breaks. Contact dealer.
104 521086
5
Electrical System
Conveyor Drive PWM
Over Load High current on circuit. Check wiring for damage.
Contact dealer.
104 521087 3
Electrical System
Master Controller High Temperature Module has exceeded max operating temperature.
Allow module to cool down before continuing operation.
REFERENCE
