215916 522 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN FMI
104 521097 6
Electrical
System
Ext. Module, Chassis Address Error CAN Address Error. Contact Dealer. Extension Module,
Chassis uses VBatt Switched Power to put 12V on an
address pin at P248-29; results in address #0 in the
control software.
104 521097
7
Electrical
System
Ext. Module, Chassis
Vref error Reference voltage error. Check wiring for damage.
104 521357 3
Electrical
System
Interlock Open
Open Load
Check wiring for damage or breaks. Contact dealer.
104 521357
4
Electrical
System
Interlock Open Over Load
High current on circuit. Check wiring for damage.
Contact dealer.
104 521359 3
Electrical
System
Brake Release Open Load
Check wiring for damage or breaks. Contact dealer.
104 521359
4
Electrical
System
Brake Release
Over Load
High current on circuit. Check wiring for damage.
Contact dealer.
104 521361 3
Electrical
System
Batt. Disc. Open
Open Load
Check wiring for damage or breaks. Contact dealer.
This circuit is an output from the Master Controller
and is connected to the Battery Disconnect Relay
"OFF" coil. This alarm will come on if the wiring,
connectors or Battery Disconnect Relay coil is
damaged.
104 521361
4
Electrical
System
Batt. Disc. Open
Over Load
High current on circuit. Check wiring for damage.
Contact dealer. This circuit is an output from the
Master Controller and is connected to the Battery
Disconnect Relay "OFF" coil. This alarm will come on if
the wiring, connectors or Battery Disconnect Relay coil
is damaged.
104 521364 3
Electrical
System
Ignition
Open Load
Check wiring for damage or breaks. Contact dealer.
104 521364
4
Electrical
System
Ignition
Over Load
High current on circuit. Check wiring for damage.
Contact dealer.
104 521366 3
Electrical
System
Starter Relay Open Load
Check wiring for damage or breaks. Contact dealer.
104 521366
4
Electrical
System
Starter Relay Over Load High current on circuit. Check wiring for damage.
Contact dealer.
