MacDon M1240 - Page 547

215916 527 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN FMI
104 521504 6
Electrical System
AHHC Right-in Sensor High Error
Sensor voltage above 4.75 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521504 8
Electrical System
AHHC Right-in Sensor Vref Error Reference voltage error. Check sensor wiring for
damage.
104 521505 3
Electrical System
AHHC Right-out Sensor Low Alarm Sensor voltage below 0.35V. Check sensor power
supply. Adjust and re-calibrate or replace sensor if necessary.
104 521505
4
Electrical System
AHHC Right-out Sensor High Alarm
Sensor voltage above 4.5 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521505
5
Electrical System
AHHC Right-out Sensor
Low Error
Sensor voltage below 0.175V. Check sensor power supply. Adjust and re-calibrate or replace sensor if necessary.
104 521505 6
Electrical System
AHHC Right-out Sensor High Error
Sensor voltage above 4.75 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521505 8
Electrical System
AHHC Right-out Sensor Vref Error Reference voltage error. Check sensor wiring for
damage.
104 521506 3
Electrical System
VREF Ext. Mod, Firewall Open Load
Check wiring for damage or breaks. Contact dealer. The following sensors may be affected:Knife SpeedReel SpeedLeft Hand Draper SpeedRight Hand Draper SpeedHeader IdentificationReel Height PositionReel Fore-Aft Position
104 521506
4
Electrical System
VREF Ext. Mod, Firewall Over Load
High current on circuit. Check wiring for damage. Contact dealer. The following sensors may be affected: Knife SpeedReel SpeedLeft Hand Draper SpeedRight Hand Draper SpeedHeader IdentificationReel Height PositionReel Fore-Aft Position
104 521507 3
Electrical System
VREF Ext. Mod, Chassis Open Load
Check wiring for damage or breaks. Contact dealer. The follwing sensors may be affected:Knife PressureReel PressureDraper PressureSupercharge PressureLeft Hand Float PositionRight Hand Float Position
104 521507
4
Electrical System
VREF Ext. Mod, Chassis
Over Load
High current on circuit. Check wiring for damage. Contact dealer. The follwing sensors may be affected: Knife PressureReel PressureDraper PressureSupercharge PressureLeft Hand Float PositionRight Hand Float Position
REFERENCE
