Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN FMI
178 521210 3
Electrical System
Low Beam Lights, EF BK5 Relay Normally Open
contact is open
Replace relay
178 521210
4
Electrical System
Low Beam Lights, EF BK5 Relay Normally Closed
contact is open
Replace relay
178 521210
5
Electrical System
Low Beam Lights, EF BK5 Relay coil is not
receiving power
Contact Dealer
178 521210 6
Electrical System
Low Beam Lights, EF BK5 Relay Normally open
contact is shorted
Replace relay
178 521210
7
Electrical System
Low Beam Lights, EF BK5 Relay Normally closed
contact is shorted
Replace relay
178 521218
1
Electrical System
LH Turn Signal Lights BK6 Relay coil open or not
present
Check chassis module for missing relay. Replace relay.
178 521218 2
Electrical System
LH Turn Signal Lights BK6 Relay Coil shorted or
failed relay driver
Replace relay
178 521218 3
Electrical System
LH Turn Signal Lights BK6 Relay Normally Open
contact is open
Replace relay
178 521218
4
Electrical System
LH Turn Signal Lights BK6 Relay Normally Closed
contact is open
Replace relay
178 521218
5
Electrical System
LH Turn Signal Lights BK6 Relay coil is not
receiving power
Contact Dealer
178 521218 6
Electrical System
LH Turn Signal Lights BK6 Relay Normally open
contact is shorted
Replace relay
178 521218
7
Electrical System
LH Turn Signal Lights BK6 Relay Normally closed
contact is shorted
Replace relay
178 521226
1
Electrical System
RH Turn Signal Lights BK3 Relay coil open or not
present
Check chassis module for missing relay. Replace relay.
178 521226 2
Electrical System
RH Turn Signal Lights BK3 Relay Coil shorted or
failed relay driver
Replace relay
178 521226 3
Electrical System
RH Turn Signal Lights BK3 Relay Normally Open
contact is open
Replace relay
178 521226
4
Electrical System
RH Turn Signal Lights BK3 Relay Normally Closed
contact is open
Replace relay
178 521226
5
Electrical System
RH Turn Signal Lights BK3 Relay coil is not
receiving power
Contact Dealer
