MacDon M1240 - Page 560

215916 540 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN FMI
178 521336 1
Electrical System
Low Beam Lights, EF BF8 Fuse Blown
Replace blown fuse in chassis relay module.
178 521336 2
Electrical System
Low Beam Lights, EF BF8 Fuse Not Powered Contact Dealer
190
444 1
Electrical System
Console 12V Low The +12V input is below the
minimum operation voltage
Contact Dealer
190 1043 2
Electrical System
Console 2.5V Low
Failure of the 2.5V A/D converter reference voltage.
Check console wiring for damage. Contact dealer.
190 2662 3
Electrical System
Throttle Voltage High Throttle input has a voltage
too high.
Check console wiring for damage. Contact dealer.
190 2662
4
Electrical System
Throttle Voltage Low Throttle input has a voltage
too low
Check console wiring for damage. Contact dealer.
190 3509 2
Electrical System
Console 5V Low The 5V internal voltage has
fallen below 4.5V.
Check console wiring for damage. Contact dealer.
190 521392 3
Electrical System
LH Turn Signal Switch Error Check switch for damage or binding. Contact dealer.
190 521393 3
Electrical System
RH Turn Signal Switch Error
Check switch for damage or binding. Contact dealer.
190 521394 3
Electrical System
Hazard Switch Error
Check switch for damage or binding. Contact dealer.
190 521395 3
Electrical System
DWA/Swath Roller Up
Switch Error Check switch for damage or binding. Contact dealer.
190 521396 3
Electrical System
DWA/Swath Roller Dn
Switch Error
Check switch for damage or binding. Contact dealer.
190 521397 3
Electrical System
Deck Shift Right Switch Error Check switch for damage or binding. Contact dealer.
190 521398 3
Electrical System
Deck Shift Center
Switch Error
Check switch for damage or binding. Contact dealer.
190 521399 3
Electrical System
Deck Shift Left
Switch Error
Check switch for damage or binding. Contact dealer.
190 521400 3
Electrical System
Draper Speed Decrease
Switch Error Check switch for damage or binding. Contact dealer.
190 521401 3
Electrical System
Draper Speed Increase Switch Error
Check switch for damage or binding. Contact dealer.
REFERENCE
